General discription
- Remote Site Management
- Cybersecurity standards UL 2900-1 and IEC 62443-4-2
- Hot-Swap network control module
- Network Cascading, connect up to 32 PDUs via network loop
- Power sharing between two network modules PDUs ensures constant access to PDU data & sensors
- 1% IEC Class 1 billing grade measurement accurancy
- Gigabit network card with 2x Gb ports
- Support protocols RestAPI, Modbus TCP, SNMP, LDAP, HTTPS
- Optional sensor Temperature/Humidity
Electrical input
Input connection: IEC-60309 32A 3Ph
Wattage: 22 kW max
Amperage Rating : 16A/ 32 A
Input voltage: 240/415V
Phase : Single Phase /Three-phase
Circuit breaker: (6) single-pole
Frequency rating: 50/60 Hz
Cord length: 3m
PDU G4 BA oU
Product Length/Depth : 1730 mm
Product Height : 53 mm
Product Width : 52 mm
Compliances : CB ,LVD Directive , RoHS Directive, WEEE Directive, Packaging Directive
Certifications: IEC 62368-1, EN IEC 63000, CE, EAC, UKCA, Cm, Ukr
PDU G4 MI 0U
Product Length/Depth: 1000 mm
Product Height: 53 mm
Product Width: 52 mm
Compliances : CB ,LVD Directive , RoHS Directive, WEEE Directive, Packaging Directive
Certifications: IEC 62368-1, EN IEC 63000, CE, EAC, UKCA, Cm, Ukr
PDU G4 SW 0U
Product Length/Depth: 1000 mm
Product Height: 53 mm
Product Width: 52 mm
Compliances : CB ,LVD Directive , RoHS Directive, WEEE Directive, Packaging Directive
Certifications: IEC 62368-1, EN IEC 63000, CE, EAC, UKCA, Cm, Ukr
PDU G4 MA 0U
Product Length/Depth: 1000 mm
Product Height: 53 mm
Product Width: 52 mm
Compliances : CB ,LVD Directive , RoHS Directive, WEEE Directive, Packaging Directive
Certifications: IEC 62368-1, EN IEC 63000, CE, EAC, UKCA, Cm, Ukr
