The 9PX UPS features ABM technology, which extends battery service life up to 50 percent, and offers flexibility in battery types with nine models offering lithium-ion batteries. Select 9PX UPS models are bundled with the Eaton Gigabit Network card, the first in the industry to comply with both UL and IEC cybersecurity standards. To complete your backup power solution, pair your 9PX with the Brightlayer Data Centers suite for seamless management of your connected equipment.
- Battery management: ABM & Temperature compensated charging method (user selectable), Automatic battery test, Deep discharge protection, Automatic recognition of external battery units
- Battery replacement: Hot-swappable internal batteries and extended battery modules (EBMs)
- Battery quantity: 15
- Battery rating: 6 Ah
- Battery type: Lithium-ion
- Extended battery capability: Yes
- Receptacle: (8) C13, (2) C19, Hardwired
- Topology: Online/Double-conversion
- Wattage: 5400 W
- VA rating: 6000 VA
- Output waveform: Sine wave
- Voltage: 230V
- Output power factor: 0.9
- Output nominal voltage: 230V default (200/208/220/230/240V)
- Output voltage range: 200/208/220/230/240 V +/- 1%
- Voltage distortion output (linear load) – max: 2
- Output frequency: 50/60 Hz
- Feed type: 1
- Input connection: Hardwired/fixed connection
- Input nominal voltage: 230V default (200/208/220/230/240V)
- Input voltage range: 176-276 V (100-276 V with derating)
- Nominal frequency: 50/60 Hz
- Input frequency range: 40-70 Hz
- Input power factor: >.99
- Communication: USB port (HID compliant), Serial port (RS232),Mini terminal block for remote On/Off
Mini-terminal block for remote power off, Dry contacts (4 outputs, relay, DB9), DB15 for parallel operation, Network card - Expansion slots: One slot, network card included
- Ethernet interface:Yes
- Includes network card: Yes
- Software compatibility: Eaton Intelligent Power Manager, Eaton Intelligent Power Protector
- User interface: Multilingual graphical LCD display
- Potential free switch contact: Yes
