Eaton 9SX UPS 200-240V Tower Only

Features

Performance and Availability

• Double-conversion topology.
• The internal bypass allows service continuity in case of internal fault, a maintenance bypass is also available (as option) for easy replacement of the UPS without powering down critical systems.
• With a 0.9 power factor the 9SX delivers 28% more power than UPS in its class. It powers more servers than other UPSs with equivalent VA ratings and lower power factors.
• Stronger, longer battery life: Eaton ABM battery management technology uses an innovative three-stage charging technique that extends battery life by up to 50%. 9SX also provides recommended replacement date for batteries.

Manageability

• The new graphical LCD provides clear information on the UPS’s status and measurements on a single screen. Enhanced configuration capabilities are also available.
• The 9SX can meter energy consumption. kWh values can be monitored using the LCD or Eaton’s Intelligent Power Software.
• Load segment control enables prioritised shutdowns of nonessential equipment to maximise battery runtime for critical devices.
• 9SX offers Serial, USB connectivity, plus an extra slot for an optional communication card. Eaton’s Intelligent Power Software seamlessly integrates with leading virtualisation environments and cloud orchestrations tools.

Flexibility

• One platform, two factors, dozens of choices. Up to 3000 VA of UPS power is packed into only 2U of rack space. The tower option is about the size of a modern, compact PC.
• More runtime can be added with up to 4 external hot-swappable battery modules, able to run systems for hours if necessary. The additional battery modules are automatically recognized by the UPS.

Advanced protection for

• IT
• Networking
• Storage
• Telecom
• Infrastructure
• Industrial
• Medical

Technical Specification

• Input Connection: C14
• Input Nominal Voltage: 230V default (200/208/220/230/240/250V)
• Nominal Frequency: 50/60 Hz
• Input Power Factor: >.99
• Input Voltage Range: 190-276 Vac without derating (up to 120-276 Vac with derating)
• Input Frequency Range: 40-70 Hz
• Output
• Output connection: C13
• Voltage: 230V
• Output power factor: 0.9
• Output voltage range: 200/208/220/230/240 V +/- 2%
• Output waveform: Sine wave
• Output nominal voltage: 230V default (200/208/220/230/240V)
• Voltage distortion output (linear load) – max: 3
• Feed type: 1
• Topology: Online/Double-conversion
• Battery
• Battery Type: Sealed, lead-acid
• Battery Replacement: Hot-swappable internal batteries and extended battery modules (EBMs)

• ABM & Temperature compensated charging method (user selectable)
• Automatic battery test
• Deep discharge protection
• Automatic recognition of external battery units
• Battery Rating: 12 V / 7 Ah
• Extended Battery Capability: Yes
• Communications
• Includes network card: No
• Communication
• USB port (HID compliant)
• Serial port (RS232)
• Mini-terminal block for remote power off
• Mini-terminal block for output relay
• Dry contacts (2 outputs, 1 input, optocoupler, DB9)
• Ethernet Interface: No
• User Interface: Multilingual graphical LCD display
• Potential Free Switch Contact: Yes
• Expansion slots: One slot for optional communication card
• Software Compatibility: Eaton Intelligent Power Manager, Eaton Intelligent Power Protector
• Type of interface: Other
• Additional Specifications
• Construction Type: Free standing model
• Phase (output): 1
• Internal bypass: Yes
• Auto shutdown function: Yes
• Efficiency: 89
• Rack mounting kit: No
• Phase (input): 1
• Hot swap power: No
• General
• Dimension (H x W x D): 252 x 160 x 387 mm
• Product Weight: 14.8 kg
• Product colour: Black

Package Contents

• UPS
• (2) IEC-IEC output cables
• USB cable
• Serial cable
• Safety instructions
• Quickstart guide
