Key features:
- High quality imaging with 2 MP, 1920 × 1080 resolution
- 24/7 color imaging with F1.0 aperture
- Smart-Hybrid light, optimize your security with flexible lighting options
- Clear imaging against strong back light due to 130 dB true WDR technology
- 3D DNR technology delivers clean and sharp images
- 2.8 mm, 3.6 mm fixed focal lens
- Up to 20 m white light distance for bright night imaging
- Up to 20 m IR distance for bright night imaging
- High quality audio with audio over coaxial cable, built-in mic
- One port for four switchable signals (TVI/AHD/CVI/CVBS)
- Water and dust resistant (IP67)
specifications
Camera
- Image Sensor 2 MP CMOS
- Max. Resolution 1920 (H) × 1080 (V)
- Min. Illumination 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with white light
- Shutter Time PAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50, 000 s
- Day & Night ICR
- Angle Adjustment Pan: 0° to 360°, Tilt: 0° to 90°, Rotation: 0° to 360°
- Signal System PAL/NTSC
- Slow Shutter Max. 16 times
Lens
- Lens Type Focal Length & FOV 2.8 mm, 3.6 mm fixed
- Focal lens 2.8 mm, horizontal FOV: 105°, vertical FOV: 56°, diagonal FOV: 123° 3.6 mm, horizontal FOV: 85°, vertical FOV: 46°, diagonal FOV: 98°
- Lens Mount M12
Microphone
- Pickup Distance In a radius of up to 5 m
- Amount 1
illuminator
- Supplement Light Type IR, White Light
- Supplement Light Type White Light IR: Up to 20 m,
- Supplement Light Range White Light: Up to 20 m
- Image Parameters Switch STD/HIGH-SAT/HIGHLIGHT
- Image Settings Brightness, Contrast, Sharpness, Anti-banding, AGC
- Frame Rate TVI: 1080p @25 fps/30 fps, CVI: 1080p @25 fps/30 fps AHD: 1080p @25 fps/30 fps CVBS: PAL/NTSC
- Day/Night Mode Auto/Color
- Wide Dynamic Range (WDR) ≥130 dB
- Image enhancement WDR, BLC, HLC, Global, HLS
- Privacy Mask 4 programmable privacy masks
- Noise Reduction 3D DNR
- White Balance Auto, Manual
Interface
- Video Output Switchable TVI/AHD/CVI/CVBS
- Alarm Solid Light Alarm(White Light)
Event
- Motion Detection 4 programmable motion areas
General
- Power 12 VDC ± 25%, max. 5.4 W *You are recommended to use one power adapter to supply the power for one camera.
- Material Plastic
- Dimension 161.1 mm × 68.4 × 65.15(6.34″ × 2.69″ × 2.57″)
- Weight Approx. 260 g (0.6 lb.)
- Operating Condition -40 °C to 60 °C (-40 °F to 140 °F). Humidity 90% or less (non-condensing)
- Communication Hikvision
- Language English
Approval
- protection IP67
