Key features:
- High quality imaging with 2 MP, 1920 × 1080 resolution
- 24/7 color imaging with F1.0 aperture
- 2.8 mm, 3.6 mm, 6 mm fixed focal lens
- Up to 40 m white light distance for bright night imaging
- Detects human body through heat-sensitive passive infrared (PIR)
- Active strobe light and audio alarm to warn intruders off
- High quality audio with audio over coaxial cable, built-in mic, and built-in speaker
- Water and dust resistant (IP67)
Camera
- Image Sensor: 2 MP CMOS
- Max. Resolution: 1920 (H) × 1080 (V)
- Min. Illumination: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with white light
- Shutter Time: PAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s
- Day & Night: 24/7 Color Imaging
- Angle Adjustment: Pan: 0° to 360°, Tilt: 0° to 180°, Rotation: 0° to 360°
- Signal System: PAL/NTSC
- Slow Shutter: Max. 16 times
Lens
- Lens Type2.8 mm, 3.6 mm, 6 mm fixed focal lens
- Focal Length & FOV: 2.8 mm, horizontal FOV: 98°, vertical FOV: 52°, diagonal FOV: 116°
3.6 mm, horizontal FOV: 77°, vertical FOV: 42°, diagonal FOV: 91°
6 mm, horizontal FOV: 51°, vertical FOV: 28°, diagonal FOV: 59°
- Lens MountM12
Illuminator
- Supplement Light Type: White Light
- Supplement Light Range: Up to 40 m
- Smart Supplement Light: Yes
- Image Parameters Switch: STD/HIGH-SAT/HIGHLIGHT
- Image Settings: Brightness, Contrast, Mirror, Defective Pixel Correction, Sharpness, Smart Light, Anti-Banding, AGC
- Frame Rate: TVI: 1080p @ 25 fps/30 fps
- Day/Night Mode: Color
- Wide Dynamic Range (WDR)≥130 dB
- Image Enhancement: WDR, BLC, HLC, Global, HLS
- Privacy Mask: 4 programmable privacy masks
- Noise Reduction: 3D DNR/2D DNR
- White Balance: Auto/Manual
Supplement Detection(PIR)
- PIR Range11 m
- PIR Angle: Angle : 110°
Interface
- Video Output1 HD analog output
- Alarm 1 line out Flashing Light Alarm (Red & Blue)
- Audio: Built-in mic
Event
- Motion Detection4 programmable motion areas
General
- Power: 12 VDC ± 25%, max. 11.4 W
*You are recommended to use one power adapter to supply the power for one camera.
- Material: Front cover: Metal, Main body: Plastic
- Dimension82.6 mm × 77.1 mm × 213.2 mm (3.25″ × 3.04″ × 8.39″)
- Approx. 467 g (1.03 lb.)
- Operating Condition; -40°C to 60°C (-40°F to 140°F), humidity: 90% or less (non-condensing)
- Communication; HIKVISION-C
- Language: English
Approval
- ProtectionIP67
