Key Features:
- 2.8 mm, 3.6 mm fixed focal lens
- Up to 25 m IR distance for bright night imaging
- Up to 20 m white light distance for bright night imaging
- One port for four switchable signals (TVI/AHD/CVI/CVBS）
- High quality audio with audio over coaxial cable, built-in mic
- Water and dust resistant (IP67)
Camera
- 2 MP CMOS image sensor
- Max. Resolution 1920 (H) × 1080 (V)
- Min. Illumination 0.01 Lux @ (F1.6, AGC ON), 0 Lux with IR
- Shutter Time PAL: 1/25 s to 1/50, 000 s; NTSC: 1/30 s to 1/50, 000 s
- Day & Night ICR
- Signal System PAL/NTSC
- Angle Adjustment Pan: 0 to 360°, Tilt: 0 to 90°, Rotation: 0 to 360°
Lens
- 2.8 mm, 3.6 mm fixed focal lens
- Focal Length & FOV 2.8 mm, horizontal FOV: 101°, vertical FOV: 56°, diagonal FOV: 118° 3.6 mm, horizontal FOV: 78°, vertical FOV: 42°, diagonal FOV: 92°
- lens mount M12
Microphone
- Pickup Distance In a radius of up to 5 m
- Amount 1
Illuminator
- Supplement light type Smart, IR, White Light
- Supplement light range IR : Up to 25 m White Light : Up to 20 m
- Image settings: Brightness, Sharpness, Smart IR
- Frame rate: TVI: 1080P @ 30 fps, 1080P @ 25 fps AHD: 1080P @ 30 fps, 1080P @ 25 fps CVI: 1080P @ 30 fps, 1080P @ 25 fps CVBS: PAL/NTSC
- Day/Night Mode Auto/Color
- Digital Wide Dynamic Range (WDR)
- Image Enhancement DWDR/BLC/HLC/Global
- White Balance Auto/Manual
- AGC Yes
Interface
- Video Output Switchable TVI/AHD/CVI/CVBS
General
- Plastic material
- Dimension 138.8 mm × 60.9 mm × 57.9 mm (5.47″ × 2.4 ” × 2.3″)
- Weight Approx. 155 g (0.34 lb.)
- Operating Condition: -40 °C to 60 °C (-40 °F to 140 °F), humidity: 90% or less (non-condensation)
- Communication: HIKVISION-C
- Language: English
- Power Supply: 12 VDC ± 25% *You are recommended to use one power adapter to supply the power for one camera.
- Consumption: Max 3.3 W
