Key Features:
- High quality imaging with 2 MP, 1920 × 1080 resolution
- 2.8 mm, 3.6 mm fixed lens
- Up to 20 m IR distance for bright night imaging
- One port for four switchable signals (TVI/AHD/CVI/CVBS)
Camera
- Image Sensor 2 MP CMOS
- Signal System PAL/NTSC
- Resolution 1920 (H) × 1080 (V)
- Frame Rate: TVI: 1080p@25fps/30fps AHD: 1080p@25fps/30fps CVI: 1080p@25fps/30fps CVBS: PAL/NTSC
- Min. Illumination: 0.02 Lux @ (F1.2, AGC ON), 0 Lux with IR
- Shutter Time: PAL: 1/25 s to 1/50,000 s; NTSC: 1/30 s to 1/50,000 s
- Lens: 2.8 mm, 3.6 mm Fixed Lens
- Field of View: 2.8 mm, horizontal FOV: 102°, vertical FOV: 55°, diagonal FOV: 123° 3.6 mm, horizontal FOV: 81°, vertical FOV: 42°, diagonal FOV: 100°
- Lens Mount: M12
- Day & Night: ICR
- Digital WDR (Wide Dynamic Range)
- Angle Adjustment Pan: 0° to 360°, Tilt: 0° to 75°, Rotation: 0° to 360°
Menu
- Image Mode: STD/HIGH-SAT
- AGC: Yes
- Day/Night Mode: Auto/Color/BW (Black and White)
- White Balance: Auto
- AE (Auto Exposure) Mode: DWDR, BLC, Global
- Noise Reduction: 2D DNR
- Language English
- Function: Brightness, Mirror, Smart IR, Sharpness
Interface
- Video Output Switchable TVI/AHD/CVI/CVBS
General
- Operating Conditions:-40°C to 60°C (-40°F to 140°F), Humidity: 90% or less (non-condensing)
- Power Supply 12 VDC ± 25%
- Consumption Max. 3.3 W
- Plastic Material
- IR Range Up to 20 m
- Communication: HIKVISION-C
- Dimension: Φ 84.6 mm × 78.9 mm (Φ 3.33″ × 3.11″)
- Weight: Approx. 195g (0.43 lb.)
