General Discription
- High quality imaging with 2 MP resolution
- Efficient H.265+ compression technology to save bandwidth and storage
- Clear imaging against strong back light due to 120 dB true WDR technology
- Audio and alarm interface available
- 3D DNR technology delivers clean and sharp images
Camera
- Image Sensor: 1/2.8″ Progressive Scan CMOS
- Max. Resolution: 1920 × 1080
- Min. Illumination: Color: 0.002 Lux @ (F1.2, AGC ON)
- Shutter Time:1/3 s to 1/100,000 s
Lens
- Focal Length & FOV: L10/L20 model:
2.8 mm: horizontal FOV: 93.9°, vertical FOV: 51.7°, diagonal FOV: 109.3°
3.7 mm: horizontal FOV: 75.5°, vertical FOV: 41.6°, diagonal FOV: 87.3°
L30 model:
2.8 mm: horizontal FOV: 107.8°, vertical FOV: 57.9°, diagonal FOV: 126.7°
4 mm: horizontal FOV: 82.8°, vertical FOV: 45.1°, diagonal FOV: 98° - Lens Mount: L10/L20: Mini
L30: M12 - Iris Type: Fixed
- Aperture: 2.8 mm: F2.5
3.7 mm: F2.5
L30:
2.8 mm: F2.0
4 mm: F2
DORI
- DORI: L10/L20:
2.8 mm: D: 47.9 m, O: 19 m, R: 9.6 m, I: 4.8 m
3.7 mm: D: 59.3 m, O: 23.5 m, R: 11.9 m, I: 5.9 m
L30:
2.8 mm: D: 42.8 m, O: 17 m, R: 8.6 m, I: 4.3 m
4 mm: D: 55.2 m, O: 21.9 m, R: 11 m, I: 5.5 m
