Hikvision 16-ch 3U 4K DeepinMind NVR iDS-9616NXI-18/X
Specifications
- Facial Recognition
- Facial Detection and AnalyticsFace picture comparison, human face capture, face picture search
- Face Picture LibraryUp to 32 face picture libraries, with up to 100,000 face pictures in total(each picture ≤ 4 MB, total capacity ≤ 20 GB)
- Facial Detection and Analytics Performance8-ch 8 MP human face capture (HD network camera, up to 8 MP, H.264/H.265)
- Face Picture Comparison16-ch face picture comparison alarm
- H.265+/H.265/H.264+/H.264 video formats
- Intelligent analytics based on deep learning algorithm
- Up to 16-ch perimeter protection
- Up to 8-ch facial recognition for video stream, or up to 16-ch facial recognition for face picture
- Up to 8-ch video structuralization
- Up to 16-ch IP cameras can be connected
- Up to 16-ch 1080p decoding capability
- Perimeter Protection
- Human/Vehicle AnalysisUp to 16-ch 4 MP (HD network camera, up to 8 MP, H.264/H.265) video analysis for human and vehicle recognition to reduce false alarm
- Video Structuralization
- Structured AnalysisUp to 8-ch 2 MP (HD network camera, up to 8 MP, H.264/H.265) live video structuralization analysis
- Face Picture LibraryUp to 32 face picture libraries, with up to 100,000 face pictures in total
- Face Picture Comparison8-ch face picture comparison alarm
- Video and Audio
- IP Video Input16-chUp to 12 MP resolution*: 32 MP and 24 MP is only available for channel 1 when ultra HD resolution mode is enabled.
- Incoming Bandwidth320 Mbps
- Outgoing Bandwidth256 Mbps
- Incoming Bandwidth (RAID Mode)200 Mbps
- Outgoing Bandwidth (RAID mode)200 Mbps
- HDMI 1 Output4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
- HDMI 2 Output1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
- VGA 1 Output1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
- VGA 2 Output1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
- Video Output ModeHDMI1/VGA1 simultaneous output, HDMI2/VGA2 simultaneous output
- CVBS OutputN/A
- Audio Output2-ch, RCA (Linear, 1 KΩ)
- Two-Way Audio1-ch, RCA (2.0 Vp-p, 1 k Ω)
- Decoding
- Decoding FormatH.265/H.265+/H.264/H.264+/MPEG4
- Decoding Capability1-ch@32 MP (30 fps)/16-ch@1080p (30 fps)
- Synchronous playback16-ch
- Recording Resolution32 MP/24 MP/12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA /4CIF/DCIF /2CIF/CIF/QCIF*: 32 MP and 24 MP is only available for channel 1 when ultra HD resolution mode is enabled.
- Stream TypeVideo, Video & Audio
- Dual-streamSupport
- Audio CompressionG.711ulaw/G.711alaw/G.722/G.726/MP2L2
- Network
- Network ProtocolTCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS
- Remote Connection128
- Network Interface2, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
- RAID
- RAID TypeRAID0, RAID1, RAID5, RAID6, RAID10
- Auxiliary Interface
- SATA8 SATA interfaces
- eSATA1 eSATA interface
- CapacityUp to 10 TB capacity for each HDD
- Serial InterfaceRS-232; RS-485; Keyboard
- USB InterfaceFront panel: 2 × USB 2.0; Rear panel: 1 × USB 3.0
- Alarm In/Out16/8
- General
- Power Supply100 to 240 VAC, 50 to 60 Hz
- Consumption≤ 70 W
- Working Temperature-10 to +55° C (+14 to +131° F)
- Working Humidity10 to 90%
- Dimension (W × D × H)445 × 465 × 92 mm (17.5″× 18.3″ × 3.6″)
- Weight≤ 10 kg (22 lb)
- Certification
- Obtained CertificationCE, FCC, UL, CB, WEEE, BIS, IC, RCM, KC, LOA
- FCCPart 15 Subpart B, ANSI C63.4
- CEEN 55032:2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4，EN 55035:2017
Professional and Reliability
- H.265+ compression effectively reduces the storage space by up to 75%
- Dual-stream recording saves bandwidth
- Adopt stream over TLS encryption technology which provides more secure stream transmission service
- Support double verification for playback and downloading
- HD Video Output
- Provide independent HDMI and VGA outputs
- HDMI video output at up to 4K resolution
- Storage and Playback
- Up to 8 SATA interfaces for HDD connection
- Up to 16-ch synchronous playback
- Smart & POS Function
- Support multiple VCA (Video Content Analytics) events
- Configurable special camera smart functions, such as VCA detection (motion, line crossing, intrusion, etc.), heat map, ANPR
- (Automatic Number-Plate Recognition), and people counting
- POS information overlay on live view and playback, and POS triggered recording and alarm
