Key Features:
- Grid and backup indication via LED
- Break before making a changeover switch
- Inverter input and output protection via circuit breakers
- Type II AC surge protection device with status indication
Eco-Friendly Design:
Manufactured using recycled materials, this backboard embodies a commitment to environmental responsibility.
Enhanced Safety:
Built-in safety features like surge protection and grounding ensure the safe operation of your inverter and connected equipment.
Streamlined Installation:
The pre-drilled mounting holes and easy-to-follow instructions facilitate a quick and hassle-free installation process.
Optimal Performance:
Engineered to optimize inverter performance, this backboard ensures efficient energy conversion and distribution.
Durable Construction:
Crafted from high-quality, UV-resistant materials, this backboard is built to withstand harsh weather conditions, guaranteeing long-lasting performance.
Improved System Organization:
The backboard provides a centralized location for mounting your inverter and other essential components, promoting a neat and organized solar setup.
Technical Data
– Max open circuit voltage Voc 460V AC
– Max current 2 Pole 63A
– Max backup port current 2 Pole 40A
– Changeover switch – centre off 2 Pole 63A SANS/IEC 60947-3
– Change over switch grid – inverter Grid – off – inverter 2 Pole 63A
– AC connection input M20 compression glands
– AC connection output M20 compression glands
– Earth connection M6 earth stud
– Breather plug M12 Incorporated
– Operating state/fault indication Green / Red
– Grid on indication Red light illuminated
– Backup port on indication Green light illuminated
– IP Rating IP65
– Double insulated Class II
– UV Protection ISO Standard 4892-2 Method A:500H
– Resistance to impact IK08
